|1.1-1.75x||2.1-5x||10 - 20x||1x||0.22x||0.05x||0.05x||0.04x|
Range of visual field
|17.1-26.2 mm||6.0-14.2 mm||1.5-3 mm||29.9 mm||135.9 mm||±28.5°||±13.4°||±22.8°|
|12.8-19.6 mm||4.5-10.7 mm||1.1-2.2 mm||22.4 mm||101.8 mm||±22.2°||±10.2°||±17.5°|
Z direction (depth of field)
|3.8-9.1 mm||0.50-2.7 mm||0.042-0.11 mm||7.8 mm||157.5 mm||500-1400 mm||650-2050 mm||800-1600 mm|
Lateral operation rate ¹
|17.5-22.1 μm||7.0-13.9 μm||2.2-3.5 μm||35.1 μm||0.11 mm||0.6 mm||0.5 mm||0.8 mm|
Z-direction repetition accuracy ²
|0.5-1 μm||0.1-0.3 μm||0.05 μm||1.5 μm||0.13 mm||1 mm||1 mm||1 mm|
Full-cycle frame rate ³
1. Lateral operation rate: The data is the best resolution obtained by the USAF1951 operation rate test card in the full range of the camera panoramic depth and full field of view.
2. Z-direction repetition accuracy (1σ):
(1) The data is tested in the camera's panoramic depth and full depth of vision;
(2) The following test method was adopted: Shot the field point calibration board at the edge of near-depth of field, focal plane and distant deep edge, and divided the FOV into 9 areas (the area of dots within the area was 1.4%FOV) at each location. The double standard deviation of 100 measurements of the B mean difference between the upper and lower calibration boards in the 27 areas was calculated, and the worst value was taken as the final result.
3 .Full-cycle frame rate: real-time shooting, calculating and saving multi-view and depth information frame rate (recommended graphics card configuration RTX3080Ti or above)
